The M350 features a panel-mounted pulse oximeter. The pilot’s heart rate and blood oxygen saturation can easily be measured and displayed on the MFD, along with continuous monitoring of carbon monoxide levels in the cabin.
HYPOXIA RECOGNITION SYSTEM WITH AUTOMATIC DESCENT MODE
The Hypoxia Recognition System detects pilot incapacitation as a result of hypoxia by monitoring pilot interaction with the PFD, MFD, and Autopilot Controller at altitudes above cabin 14,900 feet with the autopilot engaged. If no interaction is detected within a specified time period, this system will engage Automatic Descent Mode and bring the aircraft to a lower altitude in an effort to allow recovery from hypoxia. The M350 can safely fly itself, without assistance, to lower altitudes in the unlikely case the pilot becomes unresponsive.
Garmin Synthetic Vision Technology takes situational awareness to a new level, regardless of what you can or cannot see through the windshield. Acquiring information from multiple certified databases, synthetic vision graphically depicts obstacles, terrain, water, and airports, providing you with all of the information you require for safer travel.
With stall protections developed
as part of the USP system, coupled go-arounds are possible without disengaging the autopilot. With this feature, the autopilot remains engaged and will fly the missed approach. If power is not added, the USP system will maintain a speed just above stall warning, adjusting airplane pitch attitude as required.
AUTOMATIC LEVEL MODE
The M600 features the pinnacle of pilot and passenger peace of mind: Level Mode, a function that, when triggered, will return the aircraft to a wings level attitude with zero vertical speed. Upon activation, Level Mode will automatically engage the flight director and autopilot functions to return the aircraft to straight and level flight. By simply pressing the blue
button, Level Mode is activated and cancels all armed and active modes, without impeding other autopilot modes available. This ingenious additional safety measure provides further reassurance for pilot and passengers in the circumstantial case it would be required.
ELECTRONIC STABILITY PROTECTION
Preventing the onset of stalls, spins, steep spirals, and loss-of-
control conditions, this passive feature discourages aircraft operation
outside the desired flight envelope. ESP functions independently of the autopilot system, and only takes effect when the pilot is hand-flying the aircraft with the autopilot disengaged. It works as a soft barrier to keep the Piper M600 inside the preferred performance envelope by automatically engaging servos to slightly correct control surface positions when the aircraft exceeds one or more flight parameters, essentially encouraging it back inside optimal flight specifications.
GTS 33ES + GTX 825 = ADS-B IN AND OUT
The standard GTX 33ES provides ADS-B out functionality. ADS-B In can be achieved by adding the optional GTS-825 Traffic Advisory System. The GTS-825 (ADS-B In) traffic systems provide a comprehensive traffic picture. It can track up to 75 targets within a
40 nm interrogation range. Additionally, spoken ATC-like aural alerts help manage your safe flight.
Underspeed Protection (USP) is
an intuitive flight director function that reacts to underspeed conditions in a way that allows the autopilot
to remain engaged, but prevents the airplane from stalling.
